Spectral flow cytometry software
Open-source spectral cytometry with AutoSpectral built in.
Honeychrome takes you from raw data (instrument acquisition or FCS import) to unmixed data, gates, clusters and statistics in one free desktop app for macOS, Windows and Linux.
Free and open source
No licences or seats. The code is on GitHub under the LGPL, so anyone can check how the numbers are made.
Any instrument
Reads standard FCS files from spectral and conventional cytometers, and runs the Cytkit cytometer directly.
Your data stays with you
Everything runs on your own computer. Honeychrome collects no personal data and never uploads your files.
macOS, Windows, Linux
A signed app for each platform, or a Python package if you want to write your own plugins.
One workflow, from raw files to results
Each step uses the unmixing you chose, so plots, gates, clusters, statistics and exports always agree.
- Import or AcquireImport FCS files from any instrument, or interface with compatible instruments for direct acquisition
- UnmixAutoSpectral cleaning and per-cell autofluorescence
- GateBy hand, per sample, or with Automated Gating
- ClusterUMAP, FlowSOM, Leiden and automatic annotation
- CompareGroup statistics, heatmaps and volcano plots
- ReportFigures, reports, CSV and FCS exports
What's in Honeychrome 1.0.0
Everything for a spectral experiment, in one app
Unmixing
Cleaner spectra and less spread, with AutoSpectral
- AutoSpectral control cleaning picks the brightest events, matches each control to unstained cells of the same scatter and removes intrusive autofluorescent events.
- Per-cell autofluorescence: every cell is unmixed with the autofluorescence spectrum that fits it best. AF Abundance and AF Index are written out as channels you can gate on.
- Optional noise-weighted unmixing, per-cell spectral variants, and spectral correction (in beta testing) for tandem breakdown in fully stained samples.
Automated Gating
Gate once, then apply it to every sample
- Start from your Honeychrome gates or import a FlowJo workspace.
- Each gate becomes a data-driven algorithm, trained on samples you choose. Keep a gate fixed or recalculate it per sample, and nudge thresholds stricter or looser.
- Population frequencies, group statistics with heatmaps and volcano plots, sample PCA, predictive analysis and Flow Set Enrichment Analysis.
Honeycluster
From clusters to figures, without leaving the app
- Dimensionality reduction with UMAP, t-SNE, PaCMAP and PCA.
- Clustering with FlowSOM, HDBSCAN and Leiden, with a cluster tree for every method, and automatic labels from a curated cell-type and marker database.
- Differential abundance and expression with FDR control, paired designs and covariates. Lay out publication figures and write a report of each run.
Gating
Fast plots and gates, with per-sample exceptions
- Histograms, 2D density and dot plots coloured by gate, ribbon plots and logicle transforms you can drag.
- Rectangle, polygon, ellipse, quadrant and range gates on a shared gating template.
- Per-sample gating: customise a gate for one sample with a right click. Only the gates you change are stored, and every tab uses them.
Spectral library
Reference spectra for your instrument
- Browse shipped and saved reference spectra for your detector configuration and compare them.
- Use a library spectrum when a control has failed, or as the QC target for your cleaned controls.
- Save your own controls to the library, and import or export it.
Outputs
Reports, statistics and exports
- Simple Stats: bar charts, box plots, histogram overlays and a sample by marker heatmap, with CSV export.
- A DOCX report for each sample, and plots copied or exported as images.
- Unmixed FCS export in batches, written in chunks to keep memory use low.
Acquisition
Run the Cytkit cytometer
- Flow control and detector gains.
- An oscilloscope view of raw traces and live peak detection.
- Acquired data go straight into the same analysis workflow.
Works with your cytometer’s files
Honeychrome reads FCS files from spectral and conventional instruments, including:
- Cytek Aurora and Northern Lights
- Sony ID7000
- BD FACSDiscover A8 and S8
- BD FACSymphony A5SE
- Beckman Coulter CytoFLEX mosaic
- Thermo Fisher Attune Xenith
- Thermo Fisher Bigfoot
- NovoCyte Opteon
- CytoStellar
- Cytkit
- Conventional cytometers
Extend it with Python
Honeychrome is written in Python. Plugins add their own tabs with full access to the experiment, the unmixed data and the gates. To use plugins, run Honeychrome as a Python package rather than the downloaded app.
Science
AutoSpectral, tested on difficult real-world panels
AutoSpectral was tested on a 42-colour mouse tissue panel (Cytek Aurora), a 40-colour human PBMC panel (Sony ID7000) and the 50-colour OMIP-102 (BD FACSDiscover S8).
reduction in mis-assignment of the most affected cell positions in unstained samples, with per-cell autofluorescence extraction.
reduction in spillover error more broadly, across datasets.
especially in samples with variable autofluorescence, allowing multi-lineage analysis of mixed populations.
Burton OT et al. AutoSpectral improves spectral flow cytometry accuracy through optimised spectral unmixing and autofluorescence-matching at the cellular level. bioRxiv 2025. doi:10.1101/2025.10.27.684855
How it works
Who makes Honeychrome
Honeychrome is part of the Cytkit project to build a complete open-source spectral cytometer. Its main developers are Samson Rogers (Astute Devices), Oliver Burton (University of Cambridge), who developed AutoSpectral, and Angxiao Lu.
Thanks to Joan Escriva Font for faster loading of large files, to Paul Heisig (Amsterdam UMC) and David Novo for the work behind the noise model, and to Catherine Vant, Lotte Carr, Scott Tasker, Philip Jones, Robyn Pritchard and everyone who tested pre-release builds.
Built on open source
Honeychrome builds on FlowKit for gates, transforms and FCS input and output, PySide6 (Qt for Python) for the interface, pyqtgraph for fast interactive plots, NumPy and scikit-learn for analysis, and Matplotlib and Seaborn for graphics.
Found a bug or have an idea? Open an issue on GitHub. Contributions are welcome.
Try Honeychrome 1.0.0
Free for everyone. No account or licence needed.
